48.3mm diameter scaffolding steel pipe weight chart hot dipped galvanized gi pipe
48.3mm diameter scaffolding steel pipe weight chart hot dipped galvanized gi pipe
| Categories | Hot Galvanized Steel Pipe |
|---|---|
| Brand | Youfa Steel Pipe Manufacturer |
| Model | 48.3mm scaffolding steel pipe |
| Type | Galvanized Pipes |
| Material | Q195/Q235/Q355 |
| Surface finish | Galvanized Coating |
| Delivery time | Within 25 Days |
| Shape | Round Shape |
| FOB port | TIANJIN XINGANG CHINA |
| Terms of Payment | L/C, T/T |
| Download |  |
| Update Time | Apr 30,2025 |
Detail Information
Scaffolding Round Steel Pipe
EN39 BS1139
Galvanized zinc coating:
30um at average usually; customized 40um to 80um.
Pipe ends:
Plain ends free from excessive burrs.
Manufacturer certificate:
Youfa will (after production) provide an issued certificate which certify that the tubes supplied comply with this British Standard.
Exact length 1 m to 5.8m
Sample Content
Sample Content
Sample Content
Scaffold Carbon Steel Pipe Dimension Tolerance And Weight Chart
Outside diameter 1 1/2 inch; Wall thickness type 3 | Outside diameter 1 1/2 inch; Wall thickness type 4 |
Outside diameter: 48.3mm ( tolerance +/- 0.5mm ) | Outside diameter: 48.3mm ( tolerance +/- 0.5mm ) |
Thickness: 3.2mm ( tolerance -10% ) | Thickness: 4.0mm ( tolerance -10% ) |
Standard length: 6m or 6.4m ( tolerance -/+20mm ) | Standard length: 6m or 6.4m ( tolerance -/+20mm ) |
Nominal mass per unit length 3.56 kg/m | Nominal mass per unit length 4.37 kg/m |
S235GT Scaffolding Steel Pipes Technical Requirement
|
Steel Grade
|
Chemical Composition
|
Mechanical Properties
|
|||||||
|
Steel name
|
Steel number |
C
|
Mn | P | S |
Al
|
Yield strength
|
Tensile strength | Elongation |
|
% max.
|
% max. | % max. | % max. |
% min.
|
Mpa min.
|
Mpa | % min. | ||
|
S235GT
|
1.0106 |
0.20
|
1.40 | 0.040 | 0.045 |
0.020
|
235
|
340-520 | 24 |
